Today's Coronal Hole Properties | |||||
CHIMERA Number |
Centroid [Heliocentric] |
Width [°] |
Area [%] |
< B > [G] |
< Φ > [Mx] |
1 | E19S43 (-225",-726") |
E33-W55 (88) |
6.1 | -0.6 | -9.4e20 |
2 | W14N68 (88",850") |
E87-W51 (138) |
3.5 | 1.3 | 1.6e21 |
3 | W18N18 (281",205") |
W03-W28 (25) |
2.6 | 0.1 | 3.5e19 |
4 | W10S18 (163",-394") |
E05-W19 (24) |
2.0 | -0.0 | -9.8e18 |
5 | W13S51 (141",-804") |
W07-W22 (15) |
0.2 | -0.3 | -1.4e19 |
6 | W24N03 (391",-44") |
W21-W27 (6) |
0.1 | -1.7 | -3.6e19 |
7 | W45S08 (676",-199") |
W42-W48 (6) |
0.1 | 1.2 | 2.4e19 |
8 | E26S68 (-156",-923") |
E41-E22 (19) |
0.1 | -1.3 | -4.4e19 |
9 | W26S06 (427",-184") |
W24-W28 (4) |
0.0 | -2.3 | -1.5e19 |
Note: Solar Monitor's coronal hole segmentations are performed by CHIMERA, a copy of which is available at: github.com/TCDSolar/CHIMERA. The operations of the CHIMERA algorithm is described in a peer reviewed paper: arxiv.org/abs/1711.11476. An extensive copy of coronal hole properties are available at: solarmonitor.org/data. The latest positions of the coronal holes are given in heliocentric co-ordinates, and the region positions are valid on 15-Oct-2019 23:40 UT . |
